The VHF ONYX IV is a small lightweight rugged OCXO featuring low phase noise, good temperature stability and low acceleration sensitivity (to 2E-10/g per axis). Designed for Commercial and Military PCB mount applications, it provides excellent phase noise performance during vibration. The nickel-plated steel package is 1” x 1” x 0.5”. An internal voltage regulator is provided for excellent power supply line rejection. Please contact technical staff to discuss custom requirements.
Frequencies from 25 MHz to 160 MHz, fixed
Standard and Premium Phase Noise Options
Small Package; Low Profile (0.5″ ht)
Solder Sealed Steel Can
Thru Hole (PCB) Mount
Output: Sine, +13 dBm, Standard
Low-G Sensitivity to 2E-10/g per axis
Airborne
Mobile Tranceivers
Instrument Reference
