    Product Type:

    Integrated Microwave Assemblies

    Description:

    Quantic Wenzel has been an industry leading manufacturer of ultra-low noise crystal oscillators, RF modules, sub-assemblies and custom instruments, for over 35 years. Quantic Wenzel’s Integrated Microwave Assemblies (IMAs) are designed with the same innovative circuits and functionality to provide high performance components or subsystems in small lightweight packages. These oscillator-based and frequency conversion IMAs are designed for the Military, Aerospace and Commercial markets for use in radar systems, communications and electronic warfare applications. Several standard IMA products are available including the MXO Series frequency source products with outputs to 12 GHz as well as the IFM Series products, offering multiplication of low noise signals with outputs to 16 GHz. Please contact Wenzel to design and develop a custom IMA solution to meet your complex microwave system application needs.

    Model Description Application Phase Noise (100 kHz) Size

    Blue Tops RF Modules

    • Blue Tops RF Modules

    • Input Frequency from 5 MHz to 8 GHz, fixed
    • Output Frequencies to 16 GHz
    • Low Noise Amplifiers
    • Low Noise Frequency Multipliers
    • Low Noise Frequency Dividers
    • Directional Coupler, PLL, Mixer, Voltage Regulator and More
    • Low Harmonic and Spurious Content
    • Intrinsic Phase Noise Floor to -176 dBc/Hz (Input Referred)
    • Nickel-Plated Machined Aluminum Housings
    • SMA(f) Input and Output Connectors, Standard

    Airborne Radar Systems
    Tactical Radio
    Vehicular Communication
    System Synchronization
    Test Equipment

    		 to -176 dBc/Hz, intrinsic Configuration Dependent
    (See Specific RF Module Pages)
    Model Description Application Phase Noise (100 kHz) Size

    Integrated Frequency Multipliers

    • Integrated Frequency Multipliers

    • Multiplication Factors from x2 to x3200
    • Input Frequency from 5 MHz to 8 GHz, fixed
    • Output Frequencies to 16 GHz
    • Integral Multipliers, Filters, Amps and Optional Voltage Regulator
    • Intrinsic Phase Noise Floor to -176 dBc/Hz (Input Referred)
    • Nickel-Plated Machined Aluminum Housing
    • SMA(f) Input and Output Connectors, Standard

    Airborne Radar Systems
    Tactical Radio
    Vehicular Communication
    System Synchronization
    Test Equipment

    		 to -176 dBc/Hz, intrinsic Configuration Dependent
    (See Specific IFM Pages)
    Model Description Application Phase Noise (100 kHz) Size

    Custom Frequency Conversion Modules

    • Integrated Multipliers, Dividers, Amplifiers, Filters and Other Circuits

    • Input Frequencies from 5 MHz to 8 GHz, fixed
    • Output Frequencies to 16 GHz
    • Intrinsic Phase Noise Floor to -176 dBc/Hz (Input Referred)
    • Ruggedized for Dynamic Environments
    • Custom or Standard Housing Options
    • Designed to Customer Specifications or SCD/SOW
    • Testing per Customer Specifications or ATP/QTP
    • LRIP or Large Volume Production Capability
    • Project Manager Assigned
    • Responsive Customer Support

    Airborne Radar Systems
    Tactical Radio
    Vehicular Communication
    System Synchronization
    Test Equipment

    		 to -176 dBc/Hz, intrinsic Configuration Dependent
    (Consult Factory)
